Line Sets
ISOTECH UV Line SetsISO is the line set brand that HVAC professionals prefer for mini-split, residential unitary, heat pump and light commercial installations. ISO line sets out performs every other line set by keeping quality their number one priority. Superior copper, free of imperfections that cause leaks and kinks is produced from their proprietary foundry. The tough, white sheathing is highly resistant to tearing but trims clean. ISO makes every job look cleaner and more professional and is available from select wholesalers across the country.
Perfect for traditional or mini-split systems using R410A “ASK FOR ISO”
Features
- Full 1/2", 3/4", and 1" insulation
- Ideal for mini-split systems, unitary residential and heat pump installations
- Scratch/tear resistant
- Expanded polyethylene sheath
- Closed cell external LDPE covering
- Available in single or dual tube configurations
- Handy 1' markings
- 3 coil lengths – 50', 82', 164'
- Compact package footprint
Click here for ISOTECH UV Lineset Brochure
Click here for ISOPOLAR Brochure
Click here for UNIMAX Unitary Lineset Brochure
Product Certifications available upon request.
| PART NUMBER | PIPE | INSULATION | COIL LENGTH (FT) |
| SINGLE Pre-Insulated Copper Pipe Coils | |||
| ISO14-12-50 | 1/4" | 1/2" | 50 |
| ISO38-12-50 | 3/8" | 1/2" | 50 |
| ISO12-12-50 | 1/2" | 1/2" | 50 |
| ISO58-12-50 | 5/8" | 1/2" | 50 |
| ISO34-12-50 | 3/4" | 1/2" | 50 |
| ISO78-12-50 | 7/8" | 1/2" | 50 |
| ISO14-12-164 | 1/4" | 1/2" | 164 |
| ISO38-12-164 | 3/8" | 1/2" | 164 |
| ISO12-12-164 | 1/2" | 1/2" | 164 |
| ISO58-12-164 | 5/8" | 1/2" | 164 |
| ISO34-12-82 | 3/4" | 1/2" | 82 |
| ISO78-12-82 | 7/8" | 1/2" | 82 |
| ISO14-34-50 | 1/4" | 3/4" | 50 |
| ISO38-34-50 | 3/8" | 3/4" | 50 |
| ISO12-34-50 | 1/2" | 3/4" | 50 |
| ISO58-34-50 | 5/8" | 3/4" | 50 |
| ISO34-34-50 | 3/4" | 3/4" | 50 |
| ISO78-34-50 | 7/8" | 3/4" | 50 |
| ISO14-1-50 | 1/4" | 1" | 50 |
| ISO38-1-50 | 3/8" | 1" | 50 |
| ISO12-1-50 | 1/2" | 1" | 50 |
| ISO58-1-50 | 5/8" | 1" | 50 |
| ISO34-1-50 | 3/4" | 1" | 50 |
| ISO78-1-50 | 7/8" | 1" | 50 |
| DOUBLE Pre-Insulated Copper Pipe Coils | |||
| Bi14X38-12-50 | 1/4" and 3/8" | 1/2" | 50 |
| Bi14x12-12-50 | 1/4" and 1/2" | 1/2" | 50 |
| Bi14x58-12-50 | 1/4" and 5/8" | 1/2" | 50 |
| Bi38x12-12-50 | 3/8" and 1/2" | 1/2" | 50 |
| Bi38x58-12-50 | 3/8" and 5/8" | 1/2" | 50 |
ISOTECH UV
Features
- The unique solution to resist aggressive environments and corrosion
- IsoArmor polymer coating to protect the copper from moisture, oxygen and VOCs.
- External UV-retardant LDPE foil covering which adheres to a non-flammable base, melts flameless belongs to self-extinguish class
- Made in accordance with applicable regulations, with cleaned inside surfaces, phosphorous deoxidized, high residual phosphorous, annealed in coils.
- Perfect for applications where high-pressure fases are used as a refrigeration source.
- 3 coil lengths – 50', 82', 164'
- Compact package footprint Click here for Product Brochure
Product Certifications available upon request.
| PART NUMBER | PIPE | INSULATION | COIL LENGTH (FT) |
| Pre-Insulated Copper Line Sets | |||
| ISOTECHUV14-12-50 | 1/4" | 1/2" | 50 |
| ISOTECHUV38-12-50 | 3/8" | 1/2" | 50 |
| ISOTECHUV12-12-50 | 1/2" | 1/2" | 50 |
| ISOTECHUV58-12-50 | 5/8" | 1/2" | 50 |
| ISOTECHUV34-12-50 | 3/4" | 1/2" | 50 |
| ISOTECHUV78-12-50 | 7/8" | 1/2" | 50 |
| ISOTECHUV14-12-164 | 1/4" | 1/2" | 164 |
| ISOTECHUV38-12-164 | 3/8" | 1/2" | 164 |
| ISOTECHUV12-12-164 | 1/2" | 1/2" | 164 |
| ISOTECHUV58-12-164 | 5/8" | 1/2" | 164 |
| ISOTECHUV34-12-82 | 3/4" | 1/2" | 82 |
| ISOTECHUV78-12-82 | 7/8" | 1/2" | 82 |
